Nestled in the heart of Manama’s industrial landscape, Ahmer Steel has built a strong reputation as a trusted partner for high-grade materials. We take pride in supplying robust Carbon Steel F65 Forged Fittings, engineered to meet the stringent demands of modern industry. Known for their exceptional strength and reliability, these fittings are the cornerstone of durable and secure piping systems, reflecting our commitment to delivering quality and value to our clients across Bahrain and beyond.
The strength of Carbon Steel F65 comes from its carefully balanced composition, primarily iron and carbon, enhanced with elements like manganese for toughness. This formulation gives the fittings outstanding mechanical properties, including high tensile strength and excellent impact resistance. They are engineered to perform reliably under significant pressure and stress, making them a fundamentally sound choice for creating resilient and long-lasting connections in critical applications.
Standard :Ā ASTM A694 / ASME SA 694
Dimensions :Ā ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Ā 1/8″ NB to 4″ NB
Type :Ā Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure :Ā Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F65 | 0.17-0.23 | 0.15-0.40 | 1.30-1.60 | ā¤ 0.025 | ā¤ 0.015 | 0.45-0.65 | ā¤ 0.30 | ā¤ 0.30 | ā¤ 0.25 | – | 0.025~0.050 |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 65 | 77 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F65 Forged Screwed Elbows, Street Elbow, Carbon Steel F65 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F65 Reducing Coupling, Carbon Steel F65 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F65 Threaded Bushing, Carbon Steel F65 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F65 Barrel Nipples, CS F65 Forged Threaded Boss, Carbon Steel F65 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F65 High Quality Socket weld 90Ā° Elbow, Straight and Reducing-on-the-Tees, Forged 45Ā° Short Radius Elbow, CS F65 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings ā Socket Welding, Threaded, and Buttwelding Ends | CS F65 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F65 Coupling |
You’ll typically find Carbon Steel F65 Forged Fittings hard at work in environments where failure is not an option. They are essential in the oil and gas sector for refinery pipelines, in petrochemical plants handling aggressive media, and in power generation facilities. Their robustness also makes them ideal for high-pressure water systems and heavy-duty industrial processing. Essentially, wherever a system requires a connection that can withstand immense pressure, temperature fluctuations, and mechanical stress, F65 fittings provide a dependable and proven solution.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
