Situated in the industrial heart of Manama, Ahmer Steel has built a strong reputation as a trusted manufacturer and supplier of high-quality piping components. We take pride in our expertise with Carbon Steel F46 Forged Fittings, providing robust and reliable solutions for demanding industrial applications. Our commitment goes beyond mere supply; we focus on delivering products that ensure longevity and optimal performance, backed by our deep understanding of the regional market’s unique needs and challenges.
The strength of these fittings comes from their specific composition, primarily carbon, manganese, and silicon, which is carefully balanced to achieve the F46 specification. This results in a material known for its excellent tensile strength and good ductility, allowing it to withstand high pressures without compromising its integrity. This reliable combination of mechanical properties makes it a go-to material for creating durable connections that are built to handle stress and last for years under tough conditions.
Standard :Ā ASTM A694 / ASME SA 694
Dimensions :Ā ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Ā 1/8″ NB to 4″ NB
Type :Ā Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure :Ā Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F46 | 0.13-0.20 | 0.20-0.40 | 1.20-1.60 | ā¤ 0.030 | ā¤ 0.020 | – | ā¤ 0.30 | ā¤ 0.30 | ā¤ 0.25 | – | – |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 46 | 60 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F46 Forged Screwed Elbows, Street Elbow, Carbon Steel F46 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F46 Reducing Coupling, Carbon Steel F46 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F46 Threaded Bushing, Carbon Steel F46 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F46 Barrel Nipples, CS F46 Forged Threaded Boss, Carbon Steel F46 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F46 High Quality Socket weld 90Ā° Elbow, Straight and Reducing-on-the-Tees, Forged 45Ā° Short Radius Elbow, CS F46 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings ā Socket Welding, Threaded, and Buttwelding Ends | CS F46 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F46 Coupling |
You will typically find our Carbon Steel F46 Forged Fittings hard at work in critical sectors where failure is not an option. They are essential in oil and gas pipelines, power generation plants, and petrochemical refineries, effectively managing the flow of steam, water, oil, and gas. Their forged construction makes them ideal for high-pressure and high-temperature services, ensuring safety and operational continuity in everything from processing units to large-scale distribution networks.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
