Welcome to Ahmer Steel, your trusted partner in Manama, Bahrain for premium industrial solutions. We take pride in our role as a dedicated manufacturer and supplier, specializing in robust and reliable products like Carbon Steel F56 Forged Fittings. Our commitment is to deliver not just components, but reassurance, ensuring that your critical piping systems are built with integrity and precision, right from the heart of the Gulf.
At the core of these fittings is a carefully balanced carbon steel composition, designed for endurance. This specific grade offers impressive mechanical properties, including high tensile strength and excellent yield strength, which allow it to withstand significant pressure and stress. Their inherent toughness makes them exceptionally resistant to deformation, ensuring they hold their shape and seal reliably under the demanding conditions they are built for.
Standard :Ā ASTM A694 / ASME SA 694
Dimensions :Ā ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Ā 1/8″ NB to 4″ NB
Type :Ā Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure :Ā Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F56 | 0.17-0.23 | 0.15-0.40 | 1.30-1.60 | ā¤ 0.025 | ā¤ 0.015 | 0.45-0.65 | ā¤ 0.30 | ā¤ 0.30 | ā¤ 0.25 | – | 0.025~0.050 |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 65 | 77 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F56 Forged Screwed Elbows, Street Elbow, Carbon Steel F56 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F56 Reducing Coupling, Carbon Steel F56 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F56 Threaded Bushing, Carbon Steel F56 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F56 Barrel Nipples, CS F56 Forged Threaded Boss, Carbon Steel F56 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F56 High Quality Socket weld 90Ā° Elbow, Straight and Reducing-on-the-Tees, Forged 45Ā° Short Radius Elbow, CS F56 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings ā Socket Welding, Threaded, and Buttwelding Ends | CS F56 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socket weld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F56Ā Coupling |
You will find these fittings hard at work in some of the most demanding environments. They are essential in the oil and gas sector for refinery piping, and in petrochemical plants where handling aggressive fluids is a daily reality. Their reliability also makes them a go-to choice for high-pressure power generation systems, industrial processing lines, and in the construction of heavy-duty machinery, proving their worth wherever strength and a leak-proof performance are non-negotiable.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
