Located in the heart of Manama, Bahrain, Ahmer Steel has built a strong reputation as a trusted manufacturer and supplier of industrial components. Our expertise shines particularly in the production of Carbon Steel F52 Forged Fittings, which are engineered to meet the most demanding standards. We pride ourselves on delivering robust and reliable solutions that are perfectly suited for the challenging environments faced by industries throughout the region and beyond, ensuring performance you can count on every single time.
The strength of our Carbon Steel F52 fittings begins with their carefully balanced composition, which includes chromium and molybdenum for enhanced performance. This specific alloy mix grants them excellent mechanical properties, including high tensile strength and impressive yield strength, allowing them to withstand significant pressure. They also maintain good ductility and toughness, even under elevated temperatures, making them a fundamentally durable choice for critical system connections where failure is simply not an option.
Standard :Ā ASTM A694 / ASME SA 694
Dimensions :Ā ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Ā 1/8″ NB to 4″ NB
Type :Ā Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure :Ā Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F52 | 0.16-0.22 | 0.15-0.40 | 1.10-1.40 | ā¤ 0.025 | ā¤ 0.012 | 0.20-0.35 | ā¤ 0.50 | ā¤ 0.30 | ā¤ 0.25 | – | – |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 52 | 66 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F52 Forged Screwed Elbows, Street Elbow, Carbon Steel F52 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F52 Reducing Coupling, Carbon Steel F52 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F52 Threaded Bushing, Carbon Steel F52 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F52 Barrel Nipples, CS F52 Forged Threaded Boss, Carbon Steel F52 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F52 High Quality Socket weld 90Ā° Elbow, Straight and Reducing-on-the-Tees, Forged 45Ā° Short Radius Elbow, CS F52 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings ā Socket Welding, Threaded, and Buttwelding Ends | CS F52 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F52 Coupling |
You will typically find these F52 forged fittings hard at work in high-pressure systems within the oil and gas sector, as well as in power generation plants and petrochemical refineries. Their resilience makes them ideal for connecting pipes and equipment that handle corrosive fluids, steam, and other challenging media. Essentially, they are the go-to component for any application demanding a fitting that can handle both intense pressure and temperature without compromising on long-term reliability.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
