Nestled in the heart of Manama’s bustling industrial landscape, Ahmer Steel has built a reputation as a trusted partner for robust engineering solutions. Our expertise shines in the supply of Carbon Steel F42 Forged Fittings, components renowned for their formidable strength and reliability. We understand that the integrity of your piping systems is paramount, which is why we provide fittings that stand up to the most demanding conditions, ensuring your projects in Bahrain and beyond are built on a foundation of quality and lasting performance.
The exceptional performance of Carbon Steel F42 Forged Fittings stems from their specific composition and mechanical characteristics. Primarily an iron-carbon alloy, these fittings are enhanced with elements like manganese to boost toughness and strength. This formulation grants them a high tensile strength, making them incredibly resistant to breaking under pressure. They also possess good ductility, allowing them to be shaped without compromising their structural integrity, which is essential for creating secure, leak-proof connections in high-stress environments.
Standard :Ā ASTM A694 / ASME SA 694
Dimensions :Ā ASME/ANSI 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Ā 1/8″ NB to 4″ NB
Type :Ā Socketweld Fittings, Screwed-Threaded Fittings (NPT or PT Type)
Rating Pressure :Ā Threaded End – 2000 /3000/ 6000 LBS. Socket-weld End – 3000 / 6000/ 9000 LBS.
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V | Nb |
| F42 | 0.13-0.20 | 0.20-0.40 | 1.20-1.60 | ā¤ 0.030 | ā¤ 0.020 | – | ā¤ 0.30 | ā¤ 0.30 | ā¤ 0.25 | – | – |
| Grade | Yield Strength, Min (KSI ) | Tensile Strength, Min (KSI) |
| A694 | 42 | 60 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| ASME B16.11 | Factory-Made Wrought Socketweld Fittings | CS F42 Forged Screwed Elbows, Street Elbow, Carbon Steel F42 Screwed Unequal Tee, Steel Straight Tee, Carbon Steel F42 Reducing Coupling, Carbon Steel F42 Hex Plug, Forged Straight Tees, Socket Weld Pipe Cap, Forged Pipe Cap, Equal Crossess, CS F42 Threaded Bushing, Carbon Steel F42 Screwed Caps, Swedge Nipples |
| MSS-SP-79 | standard Practice covers ratings, tolerances, finish, dimensions, marking and material requirements for socket-welding | Carbon Steel F42 Barrel Nipples, CS F42 Forged Threaded Boss, Carbon Steel F42 Forged Hex Head Bull Plugs |
| MSS-SP-83 | Forged and Fabricated Socket-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Carbon Steel F42 High Quality Socket weld 90Ā° Elbow, Straight and Reducing-on-the-Tees, Forged 45Ā° Short Radius Elbow, CS F42 caps, 3000LB Socket Weld Cross |
| MSS-SP-95 | Integrally Reinforced Forged Fittings ā Socket Welding, Threaded, and Buttwelding Ends | CS F42 Socket weld Long Radius 90 Degree Elbows, Reducing Nipple, Socketweld Bushing, Threaded Plug, End Pipe caps, Carbon Steel F42 Coupling |
The inherent strength of Carbon Steel F42 Forged Fittings makes them a go-to choice for a vast array of demanding applications. You will consistently find them in critical service within the oil and gas sector, on offshore platforms and within refineries where pressure and stress are a constant. They are equally vital in power generation plants, chemical processing units, and large-scale industrial piping systems. Essentially, wherever there’s a need for a connection that can reliably handle high pressure, temperature fluctuations, and mechanical stress, these fittings provide the necessary security and durability.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
