Strategically located in the industrial heart of Manama, Ahmer Steel has built a strong reputation as a trusted manufacturer and supplier of high-grade steel products. Our expertise shines particularly in our J525 Tubing, a product engineered to meet the demanding challenges of modern industry. We understand that reliability is paramount, which is why our J525 tubing is produced with a steadfast commitment to quality and consistency, offering a robust solution for critical applications where performance and durability simply cannot be compromised.
The strength of J525 Tubing begins with its carefully balanced composition, which includes precise levels of carbon, manganese, and other key elements. This specific formulation gives the tubing its impressive mechanical properties, most notably a high yield strength that allows it to withstand significant pressure and heavy loads. It’s this combination of material integrity and proven resilience that makes J525 a dependable choice for engineers and project managers who need a material they can count on under stress.
| Grade: | ASME/ASTM SA179, SA192, SA210, SA178, SA214, API 5L |
|---|---|
| Size: | 1/8” NB TO 24” NB Sch 40/80/160/XXS |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Certification For Carbon | Mill Test Certificate as per EN 10204 / 3.2B |
| General Requirements | ASTM A 530/A 530M |
| Dimensional Tolerances | ANSI B 36.10 |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| Carbon | 0.06 – 0.18 Max |
| Manganese | 0.30 – 0.60 |
| Phosphorus | .040 Max |
| Sulfur | 0.050 Max |
| Yield Strength, min | 170 MPa |
| Ultimate Strength, min | 310 MPa |
| Elongation in 50 mm, min | 35% |
| Hardness (Rockwell B), max | 65 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| TUBING WALL THICKNESS TOLERANCES | |||
|---|---|---|---|
| Nominal Wall Thickness (Inches) | Nominal Tube OD Through 1” (+/- Inches) | Nominal Tube OD Over 1” Through 2” (+/- Inches) | Nominal Tube OD Over 2” Through 4” (+/- Inches) |
| .028 (22 Ga) | .002/.003 | .003/.003 | .003/.003 |
| .035 (20 Ga) | .002/.004 | .002/.004 | .002/.004 |
| .042 (19 Ga) | .002/.004 | .002/.004 | .002/.005 |
| .049 (18 Ga) | .004/.005 | .003/.005 | .004/.008 |
| .058 (17 Ga) | .006/.006 | .004/.008 | .004/.008 |
| .065 (16 Ga) | .006/.006 | .004/.008 | .004/.008 |
| .072 (15 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .083 (14 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .095 (13 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .100 | .006/.010 | .006/.010 | .006/.010 |
| .109 (12 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .118 | .006/.010 | .006/.010 | .006/.010 |
| .120 (11 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .134 (10 Ga) | .006/.010 | .006/.010 | .006/.010 |
| .148 (9 Ga) | — | .007/.001 | .007/.011 |
| .156 (5/32) | — | .007/.011 | .007/.011 |
| .165 (8 Ga) | — | .007/.011 | .007/.011 |
| .180 (7 Ga) | — | .007/.011 | .007/.011 |
| .197 | — | .008/0.12 | .008/0.12 |
| .203 (6 Ga) | — | .008/0.12 | .008/0.12 |
| .219 (7/32) | — | .008/.012 | .008/.012 |
| .236 | — | .014/.018 | .014/.018 |
| .238 (4 Ga) | — | .014/.018 | .014/.018 |
| .259 (3 Ga) | — | .014/.020 | .014/.020 |
You’ll find J525 Tubing hard at work in some of the most essential industries. It’s a natural fit for the demanding environments of oil and gas extraction, where it’s used in surface casing and well conduits. The construction sector relies on its strength for foundational piling and structural supports, while its durability also makes it ideal for demanding water and sewage systems. Essentially, wherever projects call for a tubing solution that offers unwavering structural integrity, J525 delivers the reliable performance needed to get the job done right.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
