Located in the industrial heart of Manama, Ahmer Steel has established itself as a trusted partner for precision-engineered steel solutions. We specialize in supplying high-quality EN10305-1 and EN10305-4 seamless steel tubing, products renowned for their exceptional reliability in demanding applications. Our commitment lies in providing not just materials, but dependable performance and expert support to industries across Bahrain and beyond, ensuring your projects are built on a foundation of quality and precision from a local source you can count on.
The composition and mechanical properties of EN10305-1 and EN10305-4 tubing are what set them apart for critical tasks. These tubes are crafted from specific steel grades, resulting in a uniform structure with outstanding strength and durability. The key difference lies in their tolerance levels; EN10305-1 offers exceptionally tight dimensional accuracy, while EN10305-4 provides a robust balance of strength and ductility. This meticulous engineering ensures they can handle high pressures and resist deformation, making them a consistently reliable choice.
| Steel Name | Steel Number | C max. | Si max. | Mn max. | P max. | S max. | AL min. |
| E215 | 1.0212 | 0.10 | 0.05 | 0.7 | 0.025 | 0.025 | 0.025 |
| 1.0308 | 0.17 | 0.35 | 1.2 | 0.025 | 0.025 | / | |
| E355 | 1.058 | 0.22 | 0.55 | 1.6 | 0.025 | 0.025 | / |
| Mechanical properties at room temperature | |||||||||||||
| Steel Grade | Minimum values for the delivery condition | ||||||||||||
| Steel Name | Steel Number | +C | +LC | +SR | +A | +N | |||||||
| Rm Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | ||
| E215 | 1.0212 | 430 | 8 | 380 | 12 | 380 | 280 | 16 | 280 | 30 | 290 to 430 | 25 | 30 |
| E235 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 350 | 16 | 315 | 25 | 340 to 480 | 235 | 25 |
| E355 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450 | 10 | 450 | 22 | 490 to 630 | 355 | 22 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a leading manufacturer and distributor of high-quality EN10305-1 / EN10305-4 Seamless Tubing in Manama, Bahrain. We offer premium steel materials and a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior precision, strength, and durability for demanding industrial applications. Contact us today for all your EN10305-1 / EN10305-4 Seamless Tubing needs!
|
Hot rolled |
Outside Diameter, mm |
Tolerance, mm |
|
OD≤101.6 |
+0.4/-0.8 |
|
|
101.6＜OD≤177.8 |
+0.4/-1.2 |
|
|
Cold Drawn |
Outside Diameter, mm |
Tolerance, mm |
|
OD＜25.4 |
±0.10 |
|
|
25.4≤OD≤38.1 |
±0.15 |
|
|
38.1＜OD＜50.8 |
±0.20 |
|
|
50.8≤OD＜63.5 |
±0.25 |
|
|
63.5≤OD＜76.2 |
±0.30 |
|
|
76.2≤OD≤101.6 |
±0.38 |
|
|
101.6＜OD≤177.8 |
+0.38/-0.64 |
|
|
Hot rolled
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤101.6, WT≤2.4 |
+40/-0 |
|
|
OD≤101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD≤101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD≤101.6, WT>4.6 |
+28/-0 |
|
|
OD>101.6, 2.4＜WT≤3.8 |
+35/-0 |
|
|
OD>101.6, 3.8＜WT≤4.6 |
+33/-0 |
|
|
OD>101.6, WT>4.6 |
+28/-0 |
|
|
Cold Drawn
|
Outside Diameter, mm |
Tolerance, % |
|
OD≤38.1 |
+20/-0 |
|
|
OD>38.1 |
+22/-0 |
The versatility of these tubing grades makes them indispensable across numerous sectors. You’ll find EN10305-1 tubing perfectly suited for high-precision hydraulic and pneumatic systems, where its exact dimensions are crucial. EN10305-4 tubing, known for its excellent pressure-bearing capacity, is widely used in automotive manufacturing, general engineering, and for structural components. From fuel injection lines and shock absorbers to machinery frames and fluid transport systems, these tubes deliver the performance needed to keep operations running smoothly and safely.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
