Nestled in the heart of Manama’s bustling industrial landscape, Ahmer Steel has built a reputation as a trusted partner for robust steel solutions. Our specialty lies in providing high-performance Carbon Steel WPHY 80 Pipe Fittings, engineered to meet the rigorous demands of modern industry. We understand that your projects require not just materials, but reliable components that ensure safety and longevity, which is precisely what our WPHY 80 fittings are designed to deliver with unwavering consistency.
The strength of these fittings comes from a specific composition that typically includes chromium, molybdenum, and nickel, creating a material known for its remarkable toughness. This carefully balanced alloy delivers exceptional mechanical properties, including a high minimum yield strength of 80,000 psi, which allows it to perform reliably under extreme pressure and in challenging low-temperature environments where other materials might fail.
| Specifications: | ASTM A860 / ASME SA860 |
|---|---|
| Size: | Seamless Butt Weld Fittings : 1/2″ – 10″, Welded Butt Weld Fittings : 1/2″ – 48″ |
| Dimensions: | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1800, BS10 |
| Thickness: | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 80, 80, XS, 100, 120, 140, 180, XXS available with NACE MR 01-75 |
| Bending Radius: | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM A860 Gr WPHY 80 Pipe Fitting |
| Type: | Seamless / Welded / Fabricated |
| Grade | C | Mn | P | S | Si | Ni | Cr | Mo | Cu | Ti | V | cb | AI | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ASTM WPHY 80 | 0.20 | 1.00-1.45 | 0.03 | 0.01 | 0.15-0.40 | 0.50 | 0.30 | 0.25 | 0.35 | 0.05 | 0.10 | 0.04 | 0.06 | |
| Element | ASTM WPHY 80 | |
|---|---|---|
| Tensile Strength (mpa) | 485 | |
| Yield Strength (mpa) | 580 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
| inch | mm | inch | Length (inch) | Center to End (inch) | Center to End (inch) | Lap Diameter (inch) | Long Length (inch) | Short Length (inch) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
Ahmer Steel is a top manufacturer and supplier of high-quality Carbon Steel WPHY 80 Pipe Fittings products in Manama, Bahrain. Specializing in steel solutions, we provide a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel. Our offerings include Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates. Known for our reliable delivery and superior customer service, we are committed to offering top-tier steel materials that ensure durability and performance across a wide range of industrial applications. We strive to meet the highest standards, making us a trusted partner for all your steel needs.
You’ll most often find these fittings hard at work in critical infrastructure where failure is not an option. They are essential in high-pressure piping systems for oil and gas transmission, powerful refinery process lines, and in demanding petrochemical plants. Their ability to withstand intense stress and resist brittle fracture also makes them an ideal choice for large-scale power generation facilities, ensuring the safe and efficient transport of steam and other aggressive media.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
