Nestled in the heart of Manama’s bustling industrial landscape, Ahmer Steel has built a strong reputation as a trusted partner for high-performance materials. We specialize in providing robust and reliable Alloy Steel T5 Tubing, a product engineered to meet the rigorous challenges of demanding environments. Our commitment goes beyond simple supply; we offer comprehensive support and expert guidance, ensuring our clients receive solutions that perfectly align with their project’s specific requirements and contribute to long-term operational success.
The strength of Alloy Steel T5 Tubing comes from its careful composition, primarily featuring chromium and molybdenum. This specific blend gives the tubing an impressive resistance to oxidation and corrosion, especially when faced with high temperatures. Mechanically, it maintains excellent tensile strength and durability under sustained stress, allowing it to perform reliably in conditions where other materials might weaken or fail, making it a consistently dependable choice.
| SA213 T5 Tube Standard | ASTM A213 T5, SA213 T5 (with IBR Test Certificate) |
|---|---|
| SA213 T5 Tube Specifications | ASTM A213 & ASTM A209 (T1 , Ta, T1b) BS/3059/90/PartII/620 & 622 DIN/17175/13CrMo44 DIN/17175/10CrMo910 DIN/17175/15Mo3 |
| SA213 T5 Tube Size | 6.35 mm OD to 101.6 mm OD |
| Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| SA213 T5 Tube Thickness | 3-12mm |
| SA213 T5 Tube Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| SA213 T5 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| Craft | Cold rolled and Cold drawn |
| SA213 T5 Tube Type | Seamless / ERW / Welded / Fabricated |
| SA213 T5 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| SA213 T5 Tube Length | Standard Double & In Cut length also. |
| SA213 T5 Tube End | Plain End, Beveled End, Treaded |
| Specialized in | ASME SA213 T5 Boiler Tube, SA213 T5 Heater Tube, SA213 T5 Heat Exchanger Tube |
| SA213 gr T5 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| SA213 grade T5 Tube Application | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| T5 | 0.15 | 0.30~0.60 | 0.025 | 0.025 | 1.0-2.0 | 0.45~0.65 |
| T5b | 0.15 max | 0.30~0.60 | 0.025 | 0.025 | 1.0-2.0 | 0.45~0.65 |
| T5c | 0.12 max | 0.30~0.60 | 0.025 max | 0.025 max | 0.50 max | 0.45~0.65 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T5 | 415 min | 205 min | 30 min | 179 max |
| T5b | 415 min | 205 min | 30 min | 179 max |
| T5c | 415 min | 205 min | 30 min | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T5 Tubing in Manama, Bahrain. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance in industrial applications with stringent requirements. Contact us today for all your Alloy Steel T5 Tubing needs!
You’ll most often find Alloy Steel T5 Tubing hard at work in power generation plants and petroleum refineries, where it is essential for constructing superheater and reheater pipes. Its ability to withstand intense heat and pressure also makes it ideal for chemical processing equipment and various high-temperature industrial piping systems. Essentially, wherever extreme conditions are the norm, this tubing provides the critical, resilient backbone for operations that demand unwavering performance and safety, proving its value day in and day out.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
