Located in the heart of Manama, Bahrain, Ahmer Steel has built a strong reputation as a trusted manufacturer and supplier of specialized steel products. We take pride in offering high-performance materials like Alloy Steel T23 Tubing, which is engineered to meet the rigorous demands of modern industry. Our commitment lies in providing reliable solutions that ensure durability and efficiency for our clients, reinforcing our position as a go-to partner for quality steel in the region and beyond.
This particular tubing is made from a chromium-molybdenum-tungsten alloy, which gives it a great combination of strength and resilience. It can handle high temperatures and pressures exceptionally well, making it less prone to creep—a gradual deformation under stress. This means components made from T23 can last significantly longer in demanding environments, offering a reliable performance that engineers and project managers can count on.
| SA213 T23 Tube Standard | ASTM A213 T23, SA213 T23 (with IBR Test Certificate) |
|---|---|
| SA213 T23 Tube Specifications | ASTM A213 & ASTM A209 (T1 , Ta, T1b) BS/3059/90/PartII/620 & 622 DIN/17175/13CrMo44 DIN/17175/10CrMo910 DIN/17175/15Mo3 |
| SA213 T23 Tube Size | 6.35 mm OD to 101.6 mm OD |
| Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| SA213 T23 Tube Thickness | 3-12mm |
| SA213 T23 Tube Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| SA213 T23 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| Craft | Cold rolled and Cold drawn |
| SA213 T23 Tube Type | Seamless / ERW / Welded / Fabricated |
| SA213 T23 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| SA213 T23 Tube Length | Standard Double & In Cut length also. |
| SA213 T23 Tube End | Plain End, Beveled End, Treaded |
| Specialized in | ASME SA213 T23 Boiler Tube, SA213 T23 Heater Tube, SA213 T23 Heat Exchanger Tube |
| SA213 gr T23 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| SA213 grade T23 Tube Application | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| T23 | 0.04~0.10 | 0.1~0.6 | 0.03max | 0.01 max | 0.5 max | 0.05~0.30 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T23 | 510 min | 400 min | 20 min | 220 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T23 Tubing in Manama, Bahrain. We offer premium steel materials and a wide range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to timely delivery and exceptional customer service, we utilize only the finest raw materials to ensure superior performance in industrial applications with demanding specifications. Contact us today for all your Alloy Steel T23 Tubing needs!
You’ll often find Alloy Steel T23 Tubing hard at work in critical areas of power generation, especially within the superheater and reheater sections of high-pressure boilers. Its ability to withstand intense heat and pressure makes it a preferred choice for these applications, helping to ensure the safe and efficient production of energy. This reliability is also valued in the petrochemical sector, where its durability contributes to the integrity of processing systems under challenging operational conditions.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
