Nestled in the industrial heart of Manama, Ahmer Steel has built a strong reputation as a trusted partner for specialized materials. We take pride in being your go-to source for high-performance alloys, particularly our reliable Alloy Steel T11 Tubing. Understanding the demanding environments our clients operate in, we ensure our T11 tubing meets the highest standards, offering a robust solution engineered for durability and exceptional performance under pressure, backed by our commitment to quality and customer support.
The strength of Alloy Steel T11 comes from its thoughtful composition, primarily chromium and molybdenum, which gives it a distinct advantage. This blend results in impressive mechanical properties, including excellent tensile strength and good creep resistance, meaning it can withstand high stresses and prolonged exposure to heat without deforming. It also offers reliable weldability and formability, making it a practical and resilient choice for fabricators who need a material that can handle both the installation process and the rigors of long-term operation.
| ASTM A213 T11 Specification & Standard | ASTM A213 T11, ASME SA213 T11 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T11 Specification | ASTM A213 & ASTM A209 (T1 , Ta, T1b) BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T11 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| ASME SA213 Grade T11 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| A213 Grade T11 Pipe Thickness | 3-12mm |
| SA213 Grade T11 Material Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| Craft | Cold rolled and Cold drawn |
| A213 Grade T11 Tube Type | Seamless / ERW / Welded / Fabricated |
| SA213 T11 Steel Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| ASME SA213 Grade T11 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| SA 213 Gr T11 Tube Length | Standard Double & In Cut length also. |
| SA213 Grade T11 Tube End | Plain End, Beveled End, Treaded |
| A213 Grade T11 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| SA 213 Gr T11 Tube Application & uses | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T11 Composition | 0.05~0.15 | 0.30~0.60 | 0.025 | 0.025 | 0.50~1.0 | 0.44~0.65 |
| Grade | SA 213 T11 Tensile Strength, MPa | Yield Strength, MPa |
|---|---|---|
| T11 | 415 min | 205 min |
| SA 213 Gr T11 Density | Elongation, % | Hardness, HB |
| 7.85 g/cc | 30 min | 179 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T11 Tubing in Manama, Bahrain. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure superior performance in industrial applications with stringent requirements. Contact us today for all your Alloy Steel T11 Tubing needs!
You’ll most often find Alloy Steel T11 tubing hard at work in power generation and petrochemical plants, where it’s essential for carrying steam, condensate, and other high-temperature fluids. Its ability to perform reliably in superheater and reheater sections of boilers makes it a cornerstone of efficient energy production. Beyond that, its corrosion resistance makes it suitable for various refinery pipelines and heat exchanger tubing, proving its versatility in any application demanding a material that won’t back down from heat and pressure.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
