Located in the heart of Manama, Bahrain, Ahmer Steel has established itself as a trusted partner for industries requiring dependable, high-performance materials. We specialize in the manufacture and supply of Alloy Steel P9 Pipes, engineered to excel in the most demanding environments. Our commitment goes beyond just supplying products; we deliver engineered solutions built on a foundation of quality assurance and a deep understanding of the rigorous challenges faced by our clients across various sectors.
The strength of Alloy Steel P9 Pipes lies in their carefully balanced composition, primarily chromium and molybdenum, which gives them exceptional mechanical properties. These pipes are renowned for their superior tensile strength and remarkable creep resistance, meaning they can withstand extreme pressures and high temperatures over long periods without deforming. This combination allows them to maintain structural integrity under continuous stress, making them a fundamentally reliable choice for critical applications.
| ASTM A335 P9 Pipe Standards | ASTM A 335, ASME SA 335 |
| Alloy Steel P9 Pipe Specialized in | Large Diameter Size |
| Alloy Steel ASTM A335 P9 Pipe Outer Dimensions | 19.05mm – 114.3mm |
| Steel P9 Pipe Wall Thickness | 2.0mm – 14 mm |
| Alloy Steel ASTM A335 P9 Pipe Length | max 16000mm |
| ASTM A335 P9 Pipe Schedule | Schedule 20 – Schedule XXS (heavier on request) up to 250 mm thk. |
| SA335 P9 Pipe Form | Round, Square, Rectangular, Hydraulic Etc. |
| Alloy Steel SA335 P9 Standard | ASTM A335 P9, SA335 P9 (with IBR Test Certificate) |
| ASTM A335 P9 Pipe Size | 1/2” NB to 36” NB |
| Alloy Steel ASTM A335 P9 Pipe Thickness | 3-12mm |
| Alloy Steel P9 Pipe Tolerance | Cold drawn pipe: +/-0.1mm
Cold rolled pipe: +/-0.05mm |
| Alloy Steel ASTM A335 P9 Pipe Craft | Cold rolled and Cold drawn |
| ASTM A335 P9 Pipe Type | Seamless / ERW / Welded / Fabricated |
| ASME SA335 P9 Pipe Length | Single Random, Double Random & Cut Length. |
| Alloy Steel ASTM A335 P9 Pipe End | Plain End, Beveled End, Treaded |
| ASTM A335 P9 Pipe Specialized in | Large Diameter A335 P9 |
| Alloy Steel P9 Pipe Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| P9 Pipe Application | Seamless Ferritic Alloy-Steel Pipe for High-Temperature Service |
| Alloy Steel P9 | C | Cr | Mn | Mo | P | S | Si |
| 0.05 – 0.15 | 0.90 – 1.10 | 0.30 – 0.60 | 0.90 – 1.10 | 0.025 max | 0.025 max | 0.25 – 1.00 |
| Tensile Strength, MPa | Yield Strength, MPa | Elongation |
| 415 min | 205 min | 30 min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Ahmer Steel is a major manufacturer and a supplier of premium Alloy Steel P9 pipe in Manama, the Bahrain. With specialization in steel solutions, we offer a variety of products including carbon steel, alloy steel, light steel and galvanized steel. Our wide bearing has pipes, pipes, flanges, pipe fittings, forged fittings, sheets and plates. We are famous for our reliable distribution and extraordinary customer service, and are committed to offering high quality steel materials that ensure durability and better performance in different industrial applications. We are committed to skill, and we are your reliable partners for all steel requirements.
| ASTM | ASME | JIS G 3458 | UNS | BS | DIN | ISO | ABS | NK | LRS |
|---|---|---|---|---|---|---|---|---|---|
| A335 P9 | SA335 P9 | STPA 26 | S50400 | 3604 P1 629-470 | 2604 II TS38 |
| O.D.(mm) x Thickness(mm) | O.D(mm) x Thickness(mm) | O.D(mm) x Thickness(mm) |
|---|---|---|
| 38.1 x 3.2 | 57.0 x 4.9 | 76.2 x 4.0 |
| 38.1 x 4.0 | 57.0 x 6.3 | 76.2 x 5.0 |
| 38.1 x 6.3 | 57.0 x 7.9 | 76.2 x 6.3 |
| 42.4 x 3.2 | 60.3 x 3.2 | 82.5 x 4.5 |
| 42.4 x 4.0 | 60.3 x 3.6 | 88.9 x 3.2 |
| 44.5 x 3.2 | 60.3 x 5.0 | 88.9 x 3.6 |
| 44.5 x 6.3 | 63.5 x 3.2 | 88.9 x 4.0 |
| 48.3 x 3.2 | 63.5 x 3.6 | 101.6 x 3.6 |
| 48.3 x 3.6 | 63.5 x 4.0 | 101.6 x 4.5 |
| 50.8 x 4.5 | 63.5 x 6.3 | 101.6 x 6.3 |
| 51.0 x 3.2 | 63.5 x 7.9 | 114.3 x 3.6 |
| 51.0 x 3.6 | 70.0 x 3.2 | 114.3 x 5.0 |
| 51.0 x 6.3 | 70.0 x 3.6 | 139.7 x 4.0 |
| 57.0 x 3.2 | 70.0 x 6.3 | 139.7 x 5.0 |
| 57.0 x 3.6 | 76.2 x 3.6 | 139.7 x 6.3 |
| ASTM A335 P9 Pipe Size NPS | Pipe O.D. | Wall Thickness | Pipe I.D. | Weight per Foot |
| 1/2 | 0.84 | 0.109 | 0.622 | 0.85 |
| 0.147 | 0.546 | 1.09 | ||
| 0.188 | 0.464 | 1.31 | ||
| 0.294 | 0.252 | 1.72 | ||
| 3/4 | 1.05 | 0.113 | 0.824 | 1.13 |
| 0.154 | 0.742 | 1.48 | ||
| 0.219 | 0.612 | 1.95 | ||
| 0.308 | 0.434 | 2.44 | ||
| 1 | 1.315 | 0.133 | 1.049 | 1.68 |
| 0.179 | 0.957 | 2.17 | ||
| 0.250 | 0.815 | 2.85 | ||
| 0.358 | 0.599 | 3.66 | ||
| 1 1/4 | 1.66 | 0.140 | 1.380 | 2.27 |
| 0.191 | 1.278 | 3.00 | ||
| 0.250 | 1.160 | 3.77 | ||
| 0.382 | 0.896 | 5.22 | ||
| 1 1/2 | 1.90 | 0.145 | 1.610 | 2.72 |
| 0.200 | 1.500 | 3.63 | ||
| 0.281 | 1.338 | 4.86 | ||
| 0.400 | 1.100 | 6.41 | ||
| 2 | 2.375 | 0.109 | 2.157 | 2.64 |
| 0.154 | 2.067 | 3.66 | ||
| 0.218 | 1.939 | 5.03 | ||
| 0.250 | 1.875 | 5.68 | ||
| 0.281 | 1.813 | 6.29 | ||
| 0.344 | 1.687 | 7.47 | ||
| 0.436 | 1.503 | 9.04 | ||
| 2 1/2 | 2.875 | 0.120 | 2.635 | 3.53 |
| 0.203 | 2.469 | 5.80 | ||
| 0.216 | 2.443 | 6.14 | ||
| 0.250 | 2.375 | 7.02 | ||
| 0.276 | 2.323 | 7.67 | ||
| 0.375 | 2.125 | 10.02 | ||
| 0.552 | 1.771 | 13.71 |
Because of their robust nature, Alloy Steel P9 Pipes are indispensable in sectors where failure is not an option. You will find them at the core of power generation plants, efficiently channeling superheated steam, and within the intricate piping systems of petroleum refineries and chemical processing units. They are also essential for high-temperature industrial heating systems and in the construction of various process equipment, proving their versatility and unmatched performance where heat and pressure are constant factors.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
