15Mo3 Pipes are top-notch alloy steel pipes provided by a reputable manufacturer and supplier based in Manama, Bahrain. They’re known for offering dependable solutions in high-temperature and high-pressure settings. Built with enhanced strength and thermal stability, these pipes find their place in boiler systems, pressure vessels, and heat exchangers. Their remarkable resistance to high temperatures and corrosive substances makes them a go-to choice for industries like power generation, petrochemicals, and refineries. Manufactured under strict quality standards, 15Mo3 Pipes guarantee outstanding performance, durability, and precise dimensions, meeting the rigorous demands of today’s industrial operations.
15Mo3 Pipes are made up of carbon, manganese, and a notable amount of molybdenum, which boosts their strength at high temperatures and resistance to corrosion. This alloy offers excellent creep resistance and stability when faced with thermal stress. On the mechanical side, 15Mo3 Pipes deliver high tensile strength, good toughness, and the capability to endure high pressure and fluctuating temperatures. Their stable microstructure ensures they remain reliable over the long haul, even in harsh working conditions. These combined chemical and mechanical traits make 15Mo3 Pipes perfect for critical applications in boilers, heat exchangers, and pressure-bearing equipment.
| Welded Pipe Size | 5.0 mm – 1219.2 mm |
|---|---|
| Grade 15Mo3 DIN 2609 EFW Pipe size | 5.0 mm – 1219.2 mm |
| CS Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
| Mild Steel Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| Carbon Steel DIN 2609 Grade 15Mo3 Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| DIN 2609 Gr 15Mo3 Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| CS Welded Tube Size | 6.35 mm OD To 152 mm OD |
| DIN 2609 Gr. 15Mo3 Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| DIN 2609 Gr St52 Carbon Steel Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| High Temperature Carbon Steel DIN 2609 Gr 15Mo3 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| DIN Gr. 2609 15Mo3 Steel Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Mild Steel Marking | All Tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Low Temperature Carbon Steel DIN 2609 Grade 15Mo3 Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| DIN Gr. 15Mo3 Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Grade 15Mo3 DIN 2609 Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| 2609 Gr. 15Mo3 End | Plain End, Beveled End, Treaded Pipe & Tube |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| 0.12 – 0.20 | 0.10 – 0.35 | 0.40 – 0.80 | 0.035 | 0.035 | 0.25 – 0.35 | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 450 | 600 | – | 22 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Ahmer Steel is a major manufacturer and a supplier of premium 15Mo3 Pipes in Manama, the Bahrain. With specialization in steel solutions, we offer a variety of products including carbon steel, alloy steel, light steel and galvanized steel. Our wide bearing has pipes, pipes, flanges, pipe fittings, forged fittings, sheets and plates. We are famous for our reliable distribution and extraordinary customer service, and are committed to offering high quality steel materials that ensure durability and better performance in different industrial applications. We are committed to skill, and we are your reliable partners for all steel requirements.
| Cold Drawn | Outside Diameter, mm | Tolerance | – |
|---|---|---|---|
| outer diameter ≤ 114 | ± 10% or ± 0.2mm | – | |
| Hot rolled | Outside Diameter, mm | Tolerance | WT/outer diameter |
| outer diameter ≤ 219.1 | ± 12.5% or ± 0.4mm | WT/outer diameter ≤ 2.5% | |
| 2.5% ＜ WT/outer diameter ≤ 5% | |||
| 5% ＜ WT/outer diameter ≤ 10% | |||
| WT/outer diameter > 10% | |||
| outer diameter > 219.1 | ± 20% | WT/outer diameter ≤ 2.5% | |
| ± 15% | 2.5% ＜ WT/outer diameter ≤ 5% | ||
| ± 12.5% | 5% ＜ WT/outer diameter ≤ 10% | ||
| ± 10% | WT/outer diameter > 10% |
15Mo3 Pipes are widely used in industries that demand reliable performance under extreme heat and pressure. You’ll find them in boiler tubes, steam lines, superheater tubes, heat exchangers, and pressure vessels. They’re a staple in power plants, chemical processing units, oil refineries, and petrochemical facilities, thanks to their excellent thermal conductivity and resistance to oxidation. These pipes excel at transporting hot gases and fluids in challenging operational environments. Their durability, creep resistance, and mechanical strength make them an ideal choice for demanding applications.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
