From the heart of Manama, Bahrain, Ahmer Steel stands as a dedicated manufacturer and supplier of high-integrity steel plates, built to thrive in the world’s most demanding environments. Our specialization in SA 516 GR.60N NACE with MR 0103-0175 certification reflects a deep commitment to quality and safety, offering clients a trusted solution for critical projects where reliability is paramount. We understand that the success of your venture depends on the materials at its core, and we take pride in providing products that ensure long-term performance and peace of mind.
These specialized plates are carefully engineered with a precise chemical composition to offer superior resistance to sulfide stress cracking, a common threat in sour service environments. This is achieved through strict control of elements like carbon, manganese, and phosphorus while enhancing hardness control for maximum durability. The resulting mechanical properties deliver an excellent balance of high tensile strength and dependable notch toughness, even at lower temperatures, making them exceptionally tough and reliable under immense pressure and corrosive conditions.
| Grade | ASME SA 516 GR.60N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.20 | 0.4 | 0.95/1.50 | 0.025 | 0.025 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength | Yield strength | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 415-550 MPa | 250 MPa | 21 | 25 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-161-430A | EN10028 P265GH | A/SA516 – Grade 60 | DIN 17155 HII |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.60N NACE and MR 0103-0175 Plates​ in Manama, Bahrain. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.60N NACE and MR 0103-0175 Plates​ needs!
The primary use for these certified plates is within the oil and gas industry, where they are essential for constructing pressure vessels, scrubbers, and separators that handle sour hydrocarbons containing hydrogen sulfide. Their robust nature also makes them ideal for critical components in petrochemical plants and refinery equipment. By choosing these plates, engineers and project managers can confidently build infrastructure that not only meets the toughest international safety standards but also ensures operational integrity and a significantly extended service life in harsh, corrosive settings.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
