Operating from Manama, Bahrain, Ahmer Steel has established itself as a trusted partner for industries demanding unwavering reliability. We are proud specialists in supplying SA 516 GR.6070N NACE Plates, a product line engineered for exceptional performance where it matters most. Our commitment is to provide materials that not only meet but exceed the rigorous standards required for challenging environments, ensuring the integrity and longevity of critical infrastructure projects across the region and beyond.
The composition of SA 516 GR.6070N NACE plates is carefully controlled, with low levels of carbon and specific alloying elements, to deliver outstanding mechanical properties. These plates are known for their high tensile strength and excellent notch toughness, even at lower temperatures. Crucially, they are heat-treated to achieve these characteristics, guaranteeing a robust and reliable material capable of withstanding significant pressure and stress in demanding service conditions.
| Grade | ASME SA 516 GR.60/70N Boiler Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.20 | 0.4 | 0.95/1.50 | 0.025 | 0.025 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| 0.18 | 0.4 | 0.95/1.50 | 0.015 | 0.008 | 0.02 (Min) | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength | Yield strength | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 415-550 MPa | 250 MPa | 21 | 25 |
| 485-620 (70-90) | 260 (38) | 17 | 21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-161-430A | EN10028 P265GH | A/SA516 – Grade 60 | DIN 17155 HII |
| BS1501-224-490A/B | EN10028 P355GH | A/SA516 – Grade 70 | – |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.60/70N NACE Plates​ in Manama, Bahrain. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.60/70N NACE Plates​ needs!
These specialized plates are essential for building equipment that operates in the presence of sour gas, which can be highly corrosive. You will typically find them in the fabrication of pressure vessels, reactors, and storage tanks for the oil and gas and petrochemical industries. Their NACE compliance makes them the material of choice for ensuring safety and preventing catastrophic failures in these critical applications, protecting both assets and personnel in harsh operational environments.
