Ahmer Steel, based in the vibrant industrial heart of Manama, Bahrain, has built a strong reputation as a trusted partner for high-quality steel. We take pride in specializing in the manufacturing and supply of SA 515 Grade 60 pressure vessel sheets and plates. Our commitment is to provide robust and reliable materials that meet the most stringent industrial demands, ensuring the integrity and safety of our clients’ critical projects throughout the region and beyond.
The strength of SA 515 Grade 60 comes from its carefully balanced composition, primarily carbon, manganese, and silicon, which is designed for excellent performance in moderate to high-temperature service. This alloy recipe gives these plates outstanding mechanical properties, including high tensile strength and superior yield strength, allowing them to withstand immense pressure. Their exceptional notch toughness is a key feature, preventing brittle fracture and ensuring long-term durability in demanding environments.
| Specifications | ASTM A515 Gr. 60 / ASME A515 Grade 60 | |
| Thickness |
|
|
| Length | 3000 mm – 8000 mm | |
| Width | 1500-3500mm | |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) | |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR) | |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | P | S | Si |
|---|---|---|---|---|---|
| A515 Grade 60 | 0.24-0.31 | 0.98 max | 0.035 max | 0.035 max | 0.13-0.45 |
| Grade | Thickness | Yield | Tensile | Elongation |
|---|---|---|---|---|
| A515 Grade 60 |  50-200mm | MPa -220 min | MPa – 415-550 | 21-25% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Because of their remarkable strength and reliability under heat and pressure, SA 515 Grade 60 plates are essential in building the backbone of heavy industry. You will find them forming the shells of boilers, massive storage tanks for oil and gas, and critical distillation columns in refineries. They are also the material of choice for large-diameter pipelines and powerful heat exchangers, proving indispensable in the energy, petrochemical, and power generation sectors where safety and performance cannot be compromised.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
