Situated in the heart of Manama’s industrial district, Ahmer Steel has built its reputation on reliability and precision, specialising in high-performance materials for demanding sectors. We take pride in introducing our Alloy Steel Grade 5 Foil, a product engineered to meet the stringent requirements of modern industry. This high-grade foil is a testament to our commitment to supplying Bahrain and the wider region with superior materials that deliver uncompromising strength and durability, supporting the ambitious projects that define our area’s growth.
The defining characteristic of this foil is its advanced composition, which incorporates elements like chromium and molybdenum to enhance its performance. This specific alloy blend gives the material exceptional mechanical properties, including a high tensile strength and remarkable resistance to wear and tear. It maintains its structural integrity even under significant stress and elevated temperatures, making it a fundamentally robust and reliable choice for applications where failure is not an option.
| Specifications | : | ASTM A387 / ASME SA387 |
| Thickness | : | 1mm-300mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4050mm etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm, 15000mm etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Alloy Steel Gr 5 | 0.15 max | 0.30-0.60 | 0.5 max | 0.035 max | 0.030 max | 4.0 – 6.0 | 0.45 – 0.65 | – | – |
| Tensile (MPa) | Yield (MPa) | Elongation (50mm) | Elongation (200mm) | Reduction of Area |
| 415 – 585 | 205 min | 18% min | – | 40% min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
The versatility of Alloy Steel Grade 5 Foil makes it indispensable across numerous fields. It is widely used to create critical components in the aerospace and automotive industries, such as specialized gaskets and shims. Its resilience also makes it perfect for protective linings in chemical processing equipment and as a vital material in the fabrication of high-performance filters and flexible heating elements. Essentially, wherever extreme conditions demand a material that is both thin and incredibly strong, this foil proves its worth.
Ahmer Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manama, Bahrain.
